14
Rev 4/2018
Speciļ¬cations
General:
Engine John Deere PowerTech 4045TF285
Overall Length 20 ft., 7 in. (6.3 m)
Overall Width 12 ft., 9 in. (3.9 m)
Overall Height 11 ft., 4 in. (3.45 m)
Weight 16,100 lbs. (7302.8 kg)
Pickup Width with Flare 76" (1.93 m)
Fuel Tank 30 gal. (113.5 L) standard; 50 gal. (189.3 L) optional
Hydraulic Oil Tank 25 gal. (94 L) total system capacity ~ 35 gal. (133 L)
Feed System Adjustable feed arm, swings on tapered bearings in sealed tube
Bullgears On tapered roller bearings
Tires:
Front 18.4-26 46 psi (317 kpa)
Rear 21.5L-16.1SL 28 psi (193 kpa)
Max Road Speed 12 mph (19.3 kph)
WARNING
Do not execute sharp turns over 8 mph (12 kph) to
prevent damaging equipment, serious injury or death.
Max Baling Speed 8 mph (12.9 kph)
Plunger:
Plunger Speed 84 strokes per minute (SPM)
Stroke Length 30 in. (76.2 cm)
Drive Bullgear (2-tie or 3-tie) or gearbox (3-tie only)
Bale Chamber: 2 Tie 3 Tie*
Height 14 in. (35.5 cm) or 16 in (40.6 cm) 16 in. (40.6 cm)
Width 18 in. (45.7 cm) 22 in. (55.9 cm)
Bale Length 18 to 52 in. (45.7 to 132 cm) 18 to 52 in. (45.7 to 132 cm)
Bale Weight 60 to 120 lbs. (27 to 54 kg) 90 to 180 lbs. (41 to 81 kg)
Knotter System:
Knotters 2 3
Twine Storage Capacity 12 rolls
Twine Type 200 to 280 knot strength
*Chamber kits available for 3-tie chambers.
