INSTRUMENTS AND CONTROLS
Defogging
To defog the windshield, turn fan control knob (B)
on and adjust temperature with temperature control
knob (A).
If the cab is still too cool, turn temperature control
knob 3 mm (1/8 in.) toward the red. Wait 3 to 4
minutes, allowing the air temperature to stabilize,
before repeating the procedure if needed.
If the A/C compressor stays off 3 to 4 minutes
and the air smells musty, move temperature control
knob (A) slightly toward the red and increase fan
speed one position.
A. Temperature control knob
B. Fan speed knob
Figure 16. Heater and Air Conditioning Controls
Adjust air louvers (see Figure 17) with tabs (C) to
prevent damage to louvers.
C
Figure 17. Air Louvers
Windshield Wiper Switch
To operate the wiper, depress the switch (see
Figure 19) to the ON position.
The windshield wiper will stop on the left-hand side
of the machine, when the switch is returned to the
OFF position.
The machine does not have a windshield washer.
Figure 18. Wiper
ON
OFF
Figure 19. Windshield Wiper Control Switch
