Fuji Xerox DocuCentre S2110

Control Panel
51
Product Overview
3
6 <Power Saver> button Press this button to enter the Power Saver mode to save the
electricity when the machine is not in use, and then the
button is lit.
Press the <Power Saver> button to exit the Power Saver
mode.
Reference
z
For more information, refer to "Power Saver Mode" (P.48).
7 <Stop> button Press this button to cancel a current job or errored job.
8 <Clear All> button Press this button to reset the displayed settings of each
feature to default values or clear the entered numbers. The
setting is returned to the same condition as the machine is
powered on.
9 <Start> button Press this button to start scanning documents or confirm
the value of each setting.
This button lights up while the machine is waiting for the
next operation. The button also blinks while the machine is
waiting for the settings to be confirmed or waiting for the
next document to scan. You cannot start a job when the
button goes out.
10 <Error> indicator Blinks when a system error occurs.
And it is lit when an error other than system errors (such as
paper jam or out of paper) occurs in the machine.
11 <Data> indicator Blinks while the machine is sending or receiving data from a
client.
12 <Last Original> button Press this button when the last document has already been
scanned.
This button blinks while the machine is scanning a
document and lights up while the machine is waiting for
the next document to scan.
13 <C> (Clear) button Press this button to delete one numerical value that you
have entered.
14 <Paper Supply> button Press this button to select a tray to use.
The tray indicator next to the selected tray moves to the
next tray on the status machine diagram every time that
the button is pressed.
Reference
z
For more information, refer to "Paper Supply" (P.103).
15 <Size (Press 2sec)> button Press this button to select the size and the orientation of
paper loaded in the selected tray.
The paper size and orientation changes on the status
machine diagram every time that the button is pressed.
Reference
z
For more information, refer to "Setting the Paper Size" (P.78).
16 Status Machine Diagram
(mimic)
Displays error locations, machine status, and other settings.
Reference
z
For more information, refer to "Machine Status" (P.54).
No. Component Description
