9.2 Cleaning the Scanner 225
5. Clean the retard pad as illustrated.
6. Clean the front rubber of the retard pad in
the direction of the arrow.
Important
• If the retard pad comes off, push it back on the
scanner until it fixes into place.
7. Lift the document feeder cover.
Note
• The read rollers can be rotated easier when the left
cover of the document feeder is open. They can also
be cleaned with the left cover closed.
8. Clean each read roller as you rotate it
towards the direction of the arrows. (There
are two read rollers.)
9. Close the left cover of the document feeder
cover until it clicks into place.
To Next Page
