Trouble shooting 2
INDOOR UNIT Error Method:
Power Frequency Abnormal
Indicate or Display:
Indoor Unit : Operation LED Flash, Timer LED Flash
Swing LED Flash
Outdoor Unit : LED1 Flash, LED6 1Time Blink
ERROR CODE : E : 04
Detective Actuators:
Indoor Unit Controller PCB Circuit
Detective details:
When 5 continuous failures occurred at Power frequency test.
Or, 2 times match under 45Hz or 2 times match over 66Hz.
Forecast of Cause : 1. Outside cause 2. Installation failure 3. Defective connection of electric components
4. Controller PCB defective
Check Point 2 : Check Installation condition
NO
Check Point 3 : Check connection of electric components
YES
p Check Cable/Breaker
p Check loose or removed connection
>> If Installation defect is found, correct it by referring
to Installation Manual.
OK
p Check power supply voltage (AC220V between Indoor
unit terminal 1 and 2)
p Check connection of Connector (any lose connector or
incorrect wiring)
p Check any shortage or corrosion on PCB.
OK
AC
Check Point 1-1 : Reset Power Supply
Does abnormal LED indication show again?
Check Point 1-2 :
Check outside cause (Voltage drop or noise, etc.)
Instant drop ----- Check if there is a large load electric apparatus
in the same circuit.
Momentary power failure ----- Check if there is a defective
contact or leak current in the
power supply circuit.
Noise ----- Check if there is any equipment causing harmonic
wave near electric line (Neon bulb or electric
equipment that may cause harmonic wave).
Check the complete insulation of grounding.
Check Point 4 : Replace Controller PCB
Change Controller PCB and set up the original address.
06-10
