02-21
SW5 setting
Refrigerant circuit address
By combined with Rotary SW7 ,the refrigerant circuit address (0-99) can be set.
Please refer "6-5-3 ADDRESS SETTING" for refrigerant address conversion table.
OFF
SW5-1
Refrigerant
circuit address
Set with Rotary
SW7,
0 - 15
16 - 31
ON
OFF
SW5-2
OFF
OFF
SW5-3 Remarks
OFF
32 - 47
OFF ON OFF
48 - 63
ON ON OFF
64 - 79
OFF OFF ON
80 - 95
ON OFF ON
96 - 99
OFF ON ON
Selecting outdoor unit series.
( Factory setting)
( Factory setting)
SW6 setting
SW7 setting
DIP SW 5-4 setting forbidden
SW 5-4
OFF
ROTARY SWITCH SETTING
Indoor unit address switch
INDOOR UNIT ADDRESS SWITCH
Refrigerant circuit address switch
SW8 setting
Remote controller address switch
By combined with DIP switch 5-1,5-2 and 5-3,the refrigerant circuit address(0 - 99)can be set.
Please refer "6-5-3 ADDRESS SETTING for type B" for the refrigerant circuit address conversion table.
When the indoor unit is wired by remote controller group, to identity the indoor unit in the remote controller group,
the number (remote controller address) in the remote controller group is set.
Set the remote controller address in the 0.1.2, ,15 order (Blank is not allowed)
REFRIGERANT CIRCUIT ADDRESS SWITCH (Factory setting : 0)
Rotary SW
SW6
Description Remarks
Indoor unit
address SW
Rotary SW
SW7
Description Remarks
Refrigerant circuit
address SW
Set with DIP switch 5-1,5-2
and 5-3
REMOTE CONTROLLER ADDRESS SWITCH (Factory setting : 0)
Rotary SW
SW8
Description Remarks
Remote controller
address
Remote controller
address
Set with DIP switch 4-1
and 4-2
(Factory setting : 0)
By combined with DIP switch 4-1 and 4-2,the indoor unit address(0 - 63)can be set.
Please refer "6-5-2 ADDRESS SETTING for type B" indoor unit address conversion table.
EXTERNAL INPUT AND OUTPUT
Connector
CN10
Input Output Remarks
CN11
CONTROL INPUT
(OPERATION / STOP)
See 2-4-2
for details
OPERATION DISPLAY
(DC12V)
To Next Page
