Check Point : ARXB07 / 09LALF
p Check each winding resistance of the motor
If Resistance value is abnormal, replace motor.
15.7 ± 8%Pink - Violet
15.7 ± 8%Violet - Blue
15.7 ± 8%Red - Pink
57.7 ± 8%Red - Black
White - Red
Read Wire
86.7 ± 8%
Resistance value(20°C)
Check Point : ARXB12 /14LALF
p Check each winding resistance of the motor
If Resistance value is abnormal, replace motor.
5.86 ± 8%Pink - Violet
5.86 ± 8%Violet - Blue
5.86 ± 8%Red - Pink
13.0 ± 8%Red - Black
White - Red
Read Wire
19.7 ± 8%
Resistance value(20°C)
Check Point : ARXB18LALF
p Check each winding resistance of the motor
If Resistance value is abnormal, replace motor.
136 ± 8%White - Yellow
Black - Yellow
Read wire
138 ± 8%
Resistance value (20°C)
06-101
