Fujitsu Airstage V series User Manual

MODELS : ARXC45, ARXC60
08-47
7
10
9
8
11
12
ARXC36 ARXC45 ARXC60
7 CASING A
8 CASING B
9 SIROCCO FAN
10 MOTOR INDUCTION
11 BRACKET MTR B
12 BRACKET(MOTOR)
Parts No.
Description
Ref
No.
Q'ty
9372057018
9372058015
9372059012
9601689027
-
9356536003
9372057018
9372058015
9372059012
9601688013
9372039007
-
9372057018
9372058015
9372059012
9601688013
9372039007
-
8
7
9
10
ARXC36
13
13
14
15
15
16
17
18
18
19
13 RUBBER (VIBRATION PROOF) 313659068604 - -
14 MOTOR MOUNT AS 9372052006 - -
15 BRACKET MTR ASSY 9372037003 9372582015 9372582015
16 PANEL FAN ASSY 9372035009 9372035009 9372035009
17 KIT(PANEL FRONT SA) 9372637029 9372637029 9372637029
18 HOOK METAL 9372055007 9372055007 9372055007
19 PANEL FRONT E 9372034002 9372034002 9372034002
