Fujitsu Airstage V series - Indoor Unit Exploded View - Models: ARXC36, ARXC45, ARXC60

MODELS :
ARXC60
ARXC36, ARXC45
08-46
1
4
3
2
5
6
ARXC36 ARXC45 ARXC60
1 PLATE TOP SA
2 KIT(PANEL LEFT SA)
3 PANEL RUGHT SA
4 KIT(PANEL MAINTE SA)
5 DRAIN PAN SA
6 DRAIN PAN S SA
Parts No.
Description
Ref
No.
Q'ty
9372576014
9372581018
9372580011
9372583012
9372579015
9372582015
9372576014
9372581018
9372580011
9372583012
9372579015
9372582015
9372576014
9372581018
9372580011
9372583012
9372579015
9372582015
