Fujitsu Airstage V series User Manual

ARXB07 ARXB09 - -
1 SIDE PANEL RIGHT SUB ASSY
2 SIDE PANEL LEFT SUB ASSY
3 FRONT PANEL SUB ASSY
4 PIPING COVER SUB ASSY
5 CABINET COVER SUB ASSY
6 DRAIN PAN SUB ASSY
Parts No.
Description
Ref
No.
Q'ty
9364505015
9364506012
9364508016
9364501031
9364503011
9364502052
9364505015
9364506012
9364508016
9364501031
9364503011
9364502052
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
MODELS : ARXB07, ARXB09
14
13
2
9
8
11
12
5
3
7
1
10
6
16
4
15
EVAPORATOR ASSY
8 DISTRIBUTOR ASSY
9 COUPLING PIPE ASSY
10 BRACKET EVA RIGHT
11 BRACKET EVA LEFT
12 SUPPORT PLATE (EVA)
9373255031
9373034162
9373038238
9363199000
9363198003
9363323009
9373255031
9373034162
9373038238
9363199000
9363198003
9363323009
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
13 AIR FILTER 9366833017 9366833017 - - -
14 HOOK METAL 9363195002 9363195002 - - -
15 THERMISTOR (PIPE-MID) 9703297052 9703297052 - - -
16 THERMISTOR (PIPE-IN) 9900220037 9900220037 - - -
7 EVAPORATOR TOTAL ASSY 9364499352 9364499352 - - -
17
17 DRAIN CAP ASSY 9377878014 9377878014 - - -
08-38
