LED1
Continuous
Lighting
Low Pressure Protection is stopped *
High Pressure Protection is stopped *
Discharge Temp. Protection is stopped *
Pump Down Completed *
Oil Balance Operation *
Test Operation *
Defrost Operation *
Oil Recovery Operation *
During Pressure Balance *
Compressors 1,2,3 Output
Compressors 2,3 Output
Compressors 1,3 Output
Compressors 1,2 Output
Compressor 3 Output
Compressor 2 Output
Compressor 1 Output
Heating mode
Cooling mode
Idling(stop) *
Indication type
Flashes 3 times
Flashes 2 times
Flashes 1 time
LED6
Flashes 2 timesLED2,3,4,5,6
Flashes 4 times
Flashes 3 times
Flashes 2 times
Flashes 1 time
LED5
Continuous lightingLED4
Flashes 7 times
Flashes 6 times
Flashes 5 times
Flashes 4 times
Flashes 3 times
Flashes 2 times
Flashes 1 time
LED3
Flashes 2 times
Flashes 1 time
LED2
LED1 Continuous Lighting
LED Flashing Pattern
Outdoor Control PCB LED Indication
SW1
SW9
SW2 SW3 SW4
SW5 SW6 SW7 SW10
SW8
LED1
LED2
LED3
LED4
LED5
LED6
LED1
LED2~6
* Please refer to Operation not trouble.
