Indoor unit fan speed switch
This switch can select fan speed corresponding to each model.
SW3 setting (Never change at the site)
Compact Cassette Type
AUXB07 AUXB09 AUXB12 AUXB14 AUXB18
SW 3-1 OFF OFF OFF OFF OFF
SW 3-2
OFF OFF OFF OFF OFF
SW 3-3 OFF OFF OFF OFF OFF
Cassette Type
AU*A20 AU*A25 AU*A30 AU*A36 AU*A45 AU*A54
SW 3-1 ON OFF OFF OFF ON OFF
SW 3-2 ON ON OFF ON OFF OFF
SW 3-3 ON ON ON OFF OFF OFF
Compact Duct Type
ARQB07 ARQB09 ARQB12 ARQB14 ARQB18
SW 3-1 OFF OFF OFF OFF OFF
SW 3-2 OFF OFF OFF OFF OFF
SW 3-3 OFF OFF OFF OFF OFF
Duct Type , Low Static Pressure Duct type
ARXB25 ARXB30 ARXB36 ARXB45
ARXA25 ARXA30 ARXA36 ARXA45
SW 3-1 OFF OFF OFF OFF
SW 3-2 OFF OFF OFF OFF
SW 3-3 OFF OFF OFF OFF
High Static Pressure Duct type
ARXC36 ARXC45 ARXC60 ARXC90
SW 3-1 OFF OFF OFF OFF
SW 3-2 OFF OFF OFF OFF
SW 3-3 OFF OFF OFF OFF
Floor Ceiling Type
AB*A12 AB*A14 AB*A18
SW 3-1 OFF OFF OFF
SW 3-2 OFF OFF OFF
SW 3-3 OFF OFF OFF
Ceiling Type
AB*A30 AB*A36 AB*A45 AB*A54
SW 3-1 OFF OFF OFF OFF
SW 3-2 OFF ON OFF ON
SW 3-3 OFF OFF ON ON
Wall mounted Type
AS*A18 AS*A24 AS*A30
SW 3-1 OFF OFF ON
SW 3-2 OFF ON ON
SW 3-3 ON ON ON
Ceiling Wall Type
AW*A07 AW*A09 AW*A12 AW*A14 AW*A18 AW*A24 AW*A30
SW 3-1 OFF ON OFF ON OFF OFF ON
SW 3-2 OFF OFF ON ON OFF ON ON
SW 3-3 OFF OFF OFF OFF ON ON ON
