MODELS :
AS*E12, AS*E14
AS*E07, AS*E09
08-67
AS*E07 AS*E09 AS*E12
1 BRACKET PANEL ASSY
2 PANEL (FRONT)
3 WIRE CLAMPER
4 CLAMPER (GRILLE)
5 AIR FILTER
6 INTAKE GRILLE ASSY
Parts No.
Description
Ref
No.
Q'ty
9312752027
9309999053
9311946014
9306755010
9309997011
9313131203
7 HOLDER (ELECTRIC FILTER) 9306602017
8 ELECTRIC FILTER 9312153015
9 ION DEODRANT FILTER 9311925033
AS*E14
9312752027
9309999053
9311946014
9306755010
9309997011
9313131203
9306602017
9312153015
9311925033
9312752027
9309999053
9311946014
9306755010
9309997011
9313131203
9306602017
9312153015
9311925033
9312752027
9309999053
9311946014
9306755010
9309997011
9313131203
9306602017
9312153015
9311925033
1
7
2
4
6
8
3
4
5
9
