05-12
7
2
6
If the Timer Mode(DELETE) button is pressed during steps or ,
the operating time for the selected day will be deleted.
If all the days are selected, the operating times for all of the day will be deleted.
3
5
Then press the ENTER button to proceed to the time setting, and repeat steps from to .
TIMER-1 TIMER-2 TIMER-3 TIMER-4
4
6
NOTES
(2) Even if the timer operation is set, the timer lamp of the
indoor unit does not light up.(The timer lamp is used for
wireless cemote controller only.)
(1) For HEAT PUMP MODEL, Does not operate according
to the settings for the HEAT timer during the cooling
mode and for the COOL or DRY timer during the heating
mode.
To set up the next timer on the same day.
To set up the timer on another day of the week and another indoor units, repeat steps from to .
To delete the operating time
Lower
Raise
Press the Start/Stop button or the Master Control button or the Set Temperature button to set the operation.
ON OFF
no
display
no setting
AUTO
COOL
DRY HEAT
FAN
no
display
no setting
* If the "ALL indoor unit" is selected and all of the indoor units are
"COOLING ONLY MODEL", it can't be selected.
*
* If the "ALL" is selected and all of the indoor units were mixture of
"HEAT PUMP MODEL" and "COOLING ONLY MODEL", it can't be selected.
*
* *
* *
no
display
no setting
depend on
initial setting
HEAT only
5
* The setting temperature range depends on
the operation mode or the initial setting.
CLOCK ADJUST
When the operating time is set, the
mark appears.
Press again the PROGRAM (
CLOCK ADJUST
) button to comp-
lete the weekly timer setting.
ex. The TIMER-1 is set 8:00 ON COOL 20 .
6
* flashes for 2 seconds.
Operation setting
To Next Page
