Quick Setup

31 G-TECH / Pro Competition User Guide, Release 3.1 31

Next, orient the G-tech as shown and press .

Next orient the G-tech as shown with the arrows

pointing up, and press .

Note: DO NOT CALIBRATE ACCELEROMETERS or ERASE ACCELEROMETER CALIBERATION 

on G-tech units which were shipped after August 2003. They have already been calibrated in the 

factory. Older G-techs will automatically request calibration. If you are unsure contact tech support.
