Chapter 2: Front panel programming
102 Vigilant VS1 and VS2 Technical Reference Manual
(fire door position, etc.). Not approved for use under ULC 527 in
Canada.
Supervisory: For supervisory devices. Momentary activation of
normally open devices immediately places the panel in a
supervisory state and turns on the supervisory LED and relay.
The device types of devices in supervisory zones control whether it
is latching or nonlatching. If all devices in the zone are latching
devices, or if you mix latching and nonlatching devices, the zone
will operate as latching.
Waterflow: Activates alarm events when a waterflow switch closes.
Select this zone type when the devices in the zone are only
connected to waterflow switches.
Note: Do not mix device and zone types. For example, do not place
a nonlatching supervisory device in an alarm zone. When the
supervisory device activates and an alarm event is initiated, the
alarm event automatically clears when the device restores without
having to reset the panel.
Label Enter a text label for the zone (two lines of 20 characters). When
you have finished, choose Save.
Correlation groups Enter the number of the correlation group. Choose Yes or No.
• “Yes” adds the item to the group.
• “No” removes the item from the group
When you have finished, choose Save. For more information on
correlation groups, see “What is a correlation group?” on page 32.
Event notification Set the active, trouble, disable, prealarm, alarm verify, maintenance
alert, and test event information by choosing one and then setting
the notification information. When you have finished, choose Save.
See “Factory default settings” on page 35 for zone event
notification default settings.
Note: If your CMS is set to zone reporting, the event notification
information sent to the receiver comes from the programming in
this section.
Printer: Yes or No. This controls whether event information is sent to
the printer
Dialer:
Acct 1 2: Event information is sent to both dialer accounts
Acct 1: Event information is sent to dialer account one
Acct 2: Event information is sent to dialer account two
None: Event information is not sent to the dialer
NET: Yes or No. Controls whether event information is sent to the
connected network
CID: Contact ID event code (000 to 999)
