Chapter 3: System operation
144 Vigilant VS1 and VS2 Technical Reference Manual
Item Description
8 Operator interface: Includes operator controls, LED indicators, and control buttons
9 Loop expander card connector (J14): Provides a connection for the optional loop
expander card (only on the VS2 panel).
10 Class A card connector (J2): Provides a connection for the optional Class A card (only
on the VS1 panel)
11 Tie wrap mounts: Used to secure wires and to help maintain proper separation
between power-limited and nonpower-limited conductors
12 LED expander connector (J6): Provides a connection for the optional LED expander
13 Standby batteries: Provide secondary/standby power to the panel electronics in the
absence of primary power
Events with event messages
Table 39: Events with event messages
Event type LCD Printer [1]
Alarm Active type reporting
Input smoke Alarm active SMK ACT
Input smoke verified Alarm active SMK ACT
Input heat Heat alarm HEAT ACT
Input heat rate of rise Heat alarm HEAT ACT
Input duct alarm Alarm active DUCT ACT
Input pull station Pull station alarm PULL ACT
Input water flow Water flow WFLW ACT
Input water flow retard Water flow WFLW ACT
Zone alarm Alarm active ALRM ACT
Zone water flow Alarm active ALRM ACT
Supervisory type reporting
Input duct alarm Supervisory DUCT ACT
Zone supervisory Supervisory SUPV ACT
Input supervisory latching Supervisory SUPV ACT
Input supervisory
nonlatching
Supervisory SUPV ACT
