Chapter 2: Front panel programming
Vigilant VS1 and VS2 Technical Reference Manual 57
the device address with the default label and serial number. This will make device
labeling much easier.
Auto programming options
Table 17 below describes the options to be set when auto programming the panel.
Table 17: Auto programming options [1]
Option Description
Auto zoning This option controls whether devices are automatically assigned to zones. The
number of devices assigned to a zone is based on the type of panel:
• VS1 panel: Four devices per zone
• VS2 panel: Sixteen devices per zone
Yes: The system automatically finds all of the devices connected to the
system and assigns them to a zone.
No: The system automatically finds all of the devices connected to the system
and does not assign them to a zone
Enable NET Configures the panel to communicate with a central monitoring station (CMS)
via an Ethernet network.
Yes: Enables Ethernet communication with the central monitoring station
(CMS).
No: Disables Ethernet communication with the CMS.
Dialer Configures the panel to communicate with the CMS via a dialer. The dialer is
configured as a dual line so that all messages are sent to two separate
receivers with different phone numbers and account codes.
Note: Not all dialer programming options are acceptable for UL/ULC
installations. See “UL 864 programming requirements” on page 31 for details.
Yes: Enables the dialer and configures it for dual-line communication with the
CMS. All messages will be sent to two separate receivers that have different
phone numbers and account codes.
No: Dialer is not enabled.
Event notification Configures event reporting for zones, individual devices, or both.
Zone: When a device is a member of a zone, only the zone information is sent
to the LCD, LEDs, printer, and dialer. Note: Device level reporting configuration
is not available.
Zone/device: Zone information is sent to the LCD and LEDs. Device
information is sent to the printer and dialer. Note: Zone/device reporting
locations can be configured through custom programming.
Device: Only device information is reported, no zone information
