Chapter 2: Front panel programming
62 Vigilant VS1 and VS2 Technical Reference Manual
Auto programming procedure
Use the following procedure to auto program the panel, referring to the options listed
in Table 17 on page 57. Not all options shown are displayed on all systems.
To auto program a panel:
1. Press the menu button and choose Program.
2. Choose Auto Program.
3. Enter a level two password.
4. When the “Current config. will be lost screen!,”
message is displayed on the LCD.
Select Continue to continue with auto programming
— or —
Select Cancel to return to the programming menu.
5. Set auto programming options.
Note: Use the right or left arrow button rather than
the Enter button to select values for each option. The
Enter button begins the auto programming operation
no matter which option the cursor is on. Also, the
options you select are preserved and will be
displayed the next time you auto program.
6. When you have finished, press Enter.
The panel begins auto programming and displays the
number of devices on the system. If you have more
than one loop, the device counts are per loop. If you
previously programmed the panel, The system
displays the number of old and new devices.
7. Press Enter to continue.
Auto programming continues based on the settings
you made above.
8. When prompted, program the options you selected
using the procedures that follow. For example, if you
are using a dialer, auto programming requires you to
program specific dialer options.
9. When auto programming is complete, the system
displays the banner screen.
Main Menu
Reports
Test
Control
Program
⇩
Program
Incremental Program
Auto Program
Advanced Program
⇩
Enter Password
0000
⇩
Current config.
will be lost!
Continue
Cancel
⇩
Auto Program
Auto Zoning Yes>
Evnt Notif Device>
Label Devices? Yes>
⇩
Auto Program
System Busy
################
<Back <Cancel
⇩
Devices Old/New
Loop 1 XXX/YYY
Loop 2 XXX/YYY
<Continue
— or —
Devices: Old/New
XXX/YYY
<Continue
