Vigilant VS1 and VS2 Technical Reference Manual 257
Appendix E
Device types to personality
codes correlation
Device types must be used when programming devices, but personality codes are
described on the Signature Series installation sheets. This table correlates the
different device types with their respective personality codes.
Table 51: Device types vs. personality codes
Model Device type Personality code
270 Pull Station (1) Alarm - NO latching (Class B)
270B Pull Station (1) Alarm - NO latching (Class B)
270F Pull Station (1) Alarm - NO latching (Class B)
270P Alarm (Ch2 only) (1) Alarm - NO latching (Class B)
270P Pull Station (Ch1 only) (1) Alarm - NO latching (Class B)
270PB Alarm (Ch2 only) (1) Alarm - NO latching (Class B)
270PB Pull Station (Ch1 only) (1) Alarm - NO latching (Class B)
271 Pull Station (1) Alarm - NO latching (Class B)
278 Pull Station (1) Alarm - NO latching (Class B)
CC1 Continuous Non-Silenceable (5) Signal - supervised output (Class B)
CC1 Continuous Non-Silenceable
(Latched)
(5) Signal - supervised output (Class B)
CC1 Continuous Silenceable (5) Signal - supervised output (Class B)
CC1 Supervised Output (5) Signal - supervised output (Class B)
CC1 Supervised Output (Latched) (5) Signal - supervised output (Class B)
CC1S Continuous Non-Silenceable (5) Signal - supervised output (Class B)
CC1S Continuous Non-Silenceable
(Latched)
(5) Signal - supervised output (Class B)
