GE Security Vigilant VS2 - System Off-Normal Display Screen

Chapter 3: System operation
Vigilant VS1 and VS2 Technical Reference Manual 133
Figure 47: LCD under normal conditions
00:00:00 01/01/07
Banner
Banner continued
Ti
me
D
ate
Banner area
System logi
n
indication
00:00:00 Login:2
System off-normal display screen
During an off-normal event, such as an alarm, supervisory, monitor, trouble,
prealarm, alarm verify, disablement, or test, the LCD screen changes to display
important information about the event. The screen displays the following:
• Time: Displays the current time
• Active points: Indicates the number of active points in the system. Increments or
decrements as devices activate and restore. If you are logged on, this information
toggles with “login.”
• Disabled points: Indicates the number of disabled points in the system. If you are
logged on, this information toggles with “login.”
• Event number: The event number (active point number) in queue
• Event type message: The event message for the type of event taking place
• Device label: The label for the device, either the default label or a custom
programmed label
