Appendix B: Worksheets
220 Vigilant VS1 and VS2 Technical Reference Manual
Zone settings worksheet
The zone settings worksheet is used to document the configuration and settings for
each of the zones on the system.
Note: Print a copy of this worksheet for each zone in the system.
Note: For default settings, see “Factory default settings” on page 35.
Type Alarm Waterflow Monitor
Supervisory (latching) Supervisory (nonlatching)
Label Line 1
Label Line 12
Correlation groups
Device allocation
First address (no less than the last address of the previous zone + 1)
Last address (first address + the number of devices – 1)
Event notification
Active
Print Yes No
NET Yes No
Dialer Acct 1 Acct 1 & 2 Acct 2 None
Code (four-digit coded output)
CID
Trouble
Print Yes No
NET Yes No
Dialer Acct 1 Acct 1 & 2 Acct 2 None
Code (four-digit coded output)
CID
To Next Page
