Appendix C: Front panel menu flowcharts
Vigilant VS1 and VS2 Technical Reference Manual 235
Advanced Program: Panel Configuration menu
N
otification
Printer Yes<>
Dialer Account1&2<>
NET Yes<>
CID 110
Save
Panel NAC
NAC 1
NAC X
Class Class A<>
Type Cont Non Sil<>
Label >
Correlation Groups
Event Notification
Save
Label
a
aaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaa
<
-Save <-Back
Event Notification
Trouble
Disable
Test
Trouble
Printer Yes<>
Dialer Account1&2<>
NET Yes<>
CID 110
Save
Annunciator
Annunciator 01
Annunciator 02
Annunciator 03
Annunciator 04
Annunciator 05
Annunciator 06
Annunciator 07
Annunciator 08
Annunciator X
Type Off<>
Expanders 1
Label
Event Notification
Save
Label
a
aaaaaaaaaaaaaaaaaaa
a
aaaaaaaaaaaaaaaaaaa
<
-Save <-Back
Trouble
Printer Yes<>
Dialer Account1&2<>
NET Yes<>
CID 110
Save
Printer
Type Supervised<>
Event Notification
Save
Advanced Program:
Panel Configuration -
CMS Device
Panel Configuration
Panel NAC
Ann. Class Class A<>
Annunciator
CMS Device
Printer
IP 192.168.001.001
MSK 255.255.255.000
GWY 192.168.001.100
Lock Rmt Read Yes<>
AC Voltage 120<>
Save
Correlation Groups
Group XXX
Status Included
<-Enter <-Exit
