Chapter 2: Front panel programming
Vigilant VS1 and VS2 Technical Reference Manual 103
To program a zone:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3. Choose Loop Configuration.
4. Choose Zone and enter the zone number.
5. Program each zone in the system using Table 26 on
page 101.
6. When you finish programming an option, choose
Save, and then continue.
7. Press the Menu button to exit menu mode, or
continue programming.
Loop Configuration
Loop Class
Zone
Correlation Groups
⇩
Zone
Number 01>
Zone 01
⇩
Zone 01
Type Alarm<>
Label >
Correlation Groups
⇩
Zone 01
Correlation Groups
Event Notification
Save
Panel programming
The panel options to be configured include:
• NAC circuits (“NACs”)
• Annunciator class
• Annunciator
• Dialer and network (“CMS device”)
• Printer
• IP address (“IP”)
• Subnet mask (“MSK”)
• Gateway (“GWY”)
Most options have a factory default setting that you can accept or change. See
“Factory default settings” on page 35.
Notes
• The option “CMS device” is only available if a dialer or network card is installed
• The option “Printer” is only available if a printer (RS-232) card is installed
• The options “IP”, “MSK”, and “GWY” are only available if a network card is installed
