GE Security Vigilant VS2 User Manual

Chapter 2: Front panel programming
Vigilant VS1 and VS2 Technical Reference Manual 127
To program the common trouble event:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3. Choose Common Trouble.
4. Choose Trouble.
5. Choose Correlation Groups.
6. Enter the correlation group number to be
programmed. (Values range from 001 to 199.).
7. Select Yes to add the common trouble to the
correlation group or No to not add the common
trouble to the correlation group.
8. Repeat steps 8 and 9 until the common trouble is
added or removed from each correlation group
needed.
9. Choose Save.
10. Choose Event Notification.
11. Choose Trouble.
12. Set trouble event notification.
Printer: Yes or No. Controls whether event
information is sent to the printer.
Coder: Enter the four-digit coded output that is
played in response to alarm conditions if a bell coder
is installed. Values range from 00-00-00-00 to 99-99-
99-99.
Dialer:
Acct 1 2: Event information is sent to both dialer
accounts
Acct 1: Event information is sent to dialer account
one
Acct 2: Event information is sent to dialer account
two
None: Event information is not sent to the dialer
NET: Yes or No. Controls whether event information is
sent to the connected network.
Advanced Program
Loop Events
Unconfigured Alarm
Common Trouble
⇩
Common Trouble
Trouble
⇩
Common Trouble
Correlation Groups
Event Notification
⇩
Correlation Groups
Group 001
Status Included
Enter Exit
⇩
Trouble
Printer Yes<>
Code 10-10-10-10
Dialer Account 1&2
⇩
Trouble
NET Yes
CID 110
Save
