Chapter 2: Front panel programming
86 Vigilant VS1 and VS2 Technical Reference Manual
To add sounder base detectors to a fast group:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3. Choose Correlation Groups and enter the correlation
group number to be programmed. Enter a value
from:
• For panels with one loop only, the fast correlation
groups are Groups 001 to 025
• For panels with two loops, the fast correlation
groups are
Loop 1: groups 001 to 025
Loop 2: groups 001 to 025 or 101 to 125 (user
configurable).
See “Programming fast groups for sounder bases” on
page 85.
4. Choose Add/Remove Device.
5. Enter the loop number (if the panel has multiple
loops).
6. Enter the device number.
7. Add the detector as an input and the sounder base
as an output. Choose:
Sensor to add the detector
— or —
Base to add the sounder base
8. On the Status line, press Enter to select Included. This
adds the device to the group.
9. Repeat steps 4 to 8 to add or remove other devices,
zones, or NACs.
10. Repeat steps 3 to 9 to program additional correlation
groups.
11. Press the Menu button to exit menu mode, or
continue programming.
Loop Configurationxxx
Loop Class
Zone
Correlation Groups
⇩
Correlation Groups
Number 001<>
⇩
Correlation Group 001
Add/Remove Zone
Add/Remove Device
Add/Rem Panel NAC
⇩
Add/Remove Device
Loop 02
⇩
Add/Remove Device
Device 001<>
⇩
Device 001
Add/Remove Sensor
Add/Remove Base
⇩
Add/Remove Sensor 001
Status Included
