GE Power Management 745 Transformer Management Relay 11-11
11 SETPOINT TABLES 11.1 COMMISSIONING SUMMARY
11
W2 Gnd Inst O/C 1 Function Disabled
W2 Gnd Inst O/C 1 Target Latched
W2 Gnd Inst O/C 1 Pickup 10.00 x CT
W2 Gnd Inst O/C 1 Delay 0 ms
W2 Gnd Inst O/C 1 Block Disabled
W3 Gnd Inst O/C 1 Function Disabled
W3 Gnd Inst O/C 1 Target Latched
W3 Gnd Inst O/C 1 Pickup 10.00 x CT
W3 Gnd Inst O/C 1 Delay 0 ms
W3 Gnd Inst O/C 1 Block Disabled
W1 Gnd Inst O/C 2 Function Disabled
W1 Gnd Inst O/C 2 Target Latched
W1 Gnd Inst O/C 2 Pickup 10.00 x CT
W1 Gnd Inst O/C 2 Delay 0 ms
W1 Gnd Inst O/C 2 Block Disabled
W2 Gnd Inst O/C 2 Function Disabled
W2 Gnd Inst O/C 2 Target Latched
W2 Gnd Inst O/C 2 Pickup 10.00 x CT
W2 Gnd Inst O/C 2 Delay 0 ms
W2 Gnd Inst O/C 2 Block Disabled
W3 Gnd Inst O/C 2 Function Disabled
W3 Gnd Inst O/C 2 Target Latched
W3 Gnd Inst O/C 2 Pickup 10.00 x CT
W3 Gnd Inst O/C 2 Delay 0 ms
W3 Gnd Inst O/C 2 Block Disabled
RESTRICTED GROUND FAULT
W1 Rstd Gnd Fault Function Disabled
W1 Rstd Gnd Fault Target Latched
W1 Rstd Gnd Fault Pickup 0.08 x CT
W1 Rstd Gnd Fault Slope 10%
W1 Rstd Gnd Fault Delay 0.10 s
W1 Rstd Gnd Fault Block Disabled
W2 Rstd Gnd Fault Function Disabled
W2 Rstd Gnd Fault Target Latched
W2 Rstd Gnd Fault Pickup 0.08 x CT
Table 11–6: S4 ELEMENTS (Sheet 6 of 12)
