11-14 745 Transformer Management Relay GE Power Management
11.1 COMMISSIONING SUMMARY 11 SETPOINT TABLES
11
Underfrequency 2 Function Disabled
Underfrequency 2 Target Self-reset
Underfrequency 2 Min. Current 0.20 x CT
Underfrequency 2 Pickup 58.80 Hz
Underfrequency 2 Delay 1.00 s
Underfrequency 2 Block Disabled
Frequency Decay Function Disabled
Frequency Decay Target Latched
Current Sensing Enabled
Frequency Decay Min. Current 0.20 x CT
Minimum Operating Voltage 0.50 x VT
Frequency Decay Threshold 59.50 Hz
Frequency Decay Delay 0.00 s
Frequency Decay Rate 1 0.4 Hz/s
Frequency Decay Rate 2 1.0 Hz/s
Frequency Decay Rate 3 2.0 Hz/s
Frequency Decay Rate 4 4.0 Hz/s
Frequency Decay Block Disabled
Overfrequency Function Disabled
Overfrequency Target Latched
Current Sensing Enabled
Overfrequency Min. Current 0.20 x CT
Minimum Operating Voltage 0.50 x VT
Overfrequency Pickup 60.50 Hz
Overfrequency Delay 5.00 s
Overfrequency Block Disabled
OVEREXCITATION
5th Harmonic Level Function Disabled
5th Harmonic Level Target Self-reset
5th Harmonic Level Min. Current 0.10 x CT
5th Harmonic Level Pickup 10.0% ƒo
5th Harmonic Level Delay 10 s
5th Harmonic Level Block Disabled
Volts-Per-Hertz 1 Function Disabled
Volts-Per-Hertz 1 Target Self-reset
Table 11–6: S4 ELEMENTS (Sheet 9 of 12)
DESCRIPTION DEFAULT GROUP 1 GROUP 2 GROUP 3 GROUP 4
