GE Power Management 745 Transformer Management Relay 11-15
11 SETPOINT TABLES 11.1 COMMISSIONING SUMMARY
11
Volts-Per-Hertz 1 Min. Voltage 0.10 x VT
Volts-Per-Hertz 1 Pickup 2.36 V/Hz
Volts-Per-Hertz 1 Shape Def. Time
Volts-Per-Hertz 1 Delay 2.00 s
Volts-Per-Hertz 1 Reset 0.0 s
Volts-Per-Hertz 1 Block Disabled
Volts-Per-Hertz 2 Function Disabled
Volts-Per-Hertz 2 Target Self-reset
Volts-Per-Hertz 2 Min. Voltage 0.10 x VT
Volts-Per-Hertz 2 Pickup 2.14 V/Hz
Volts-Per-Hertz 2 Shape Def. Time
Volts-Per-Hertz 2 Delay 45.00 s
Volts-Per-Hertz 2 Reset 0.0 s
Volts-Per-Hertz 2 Block Disabled
HARMONICS
W1 THD Level Function Disabled
W1 THD Level Target Self-reset
W1 THD Level Min. Current 0.10 x CT
W1 THD Level Pickup 50.0 % f
o
W1 THD Level Delay 10 s
W1 THD Level Block Disabled
W2 THD Level Function Disabled
W2 THD Level Target Self-reset
W2 THD Level Min. Current 0.10 x CT
W2 THD Level Pickup 50.0 % f
o
W2 THD Level Delay 10 s
W2 THD Level Block Disabled
W3 THD Level Function Disabled
W3 THD Level Target Self-reset
W3 THD Level Min. Current 0.10 x CT
W3 THD Level Pickup 50.0 % f
o
W3 THD Level Delay 10 s
W3 THD Level Block Disabled
W1 Harmonic Derating Function Disabled
W1 Harmonic Derating Target Self-reset
Table 11–6: S4 ELEMENTS (Sheet 10 of 12)
DESCRIPTION DEFAULT GROUP 1 GROUP 2 GROUP 3 GROUP 4
