11-16 745 Transformer Management Relay GE Power Management
11.1 COMMISSIONING SUMMARY 11 SETPOINT TABLES
11
W1 Harm. Derating Min Current 0.10 x CT
W1 Harmonic Derating Pickup 0.90
W1 Harmonic Derating Delay 10 s
W1 Harmonic Derating Block Disabled
W2 Harmonic Derating Function Disabled
W2 Harmonic Derating Target Self-reset
W2 Harm. Derating Min. Current 0.10 x CT
W2 Harmonic Derating Pickup 0.90
W2 Harmonic Derating Delay 10 s
W2 Harmonic Derating Block Disabled
W3 Harmonic Derating Function Disabled
W3 Harmonic Derating Target Self-reset
W3 Harm. Derating Min. Current 0.10 x CT
W3 Harmonic Derating Pickup 0.90
W3 Harmonic Derating Delay 10 s
W3 Harmonic Derating Block Disabled
INSULATION AGING
Hottest Spot Limit Disabled
Hottest Spot Limit Target Self-Reset
Hottest Spot Limit Pickup 150ºC
Hottest Spot Limit Delay 10 min
Hottest Spot Limit Block Disabled
AGING FACTOR LIMIT
Aging Factor Limit Function Disabled
Aging Factor Limit Target Self -reset
Aging Factor Limit Pickup 2.0
Aging Factor Limit Delay 10 min
Aging Factor Limit Block disabled
LOSS-OF-LIFE LIMIT
Loss of Life Limit Function Disabled
Loss of Life Limit Target Self-Reset
Loss of Life Limit Pickup 16000 x 10h
Loss of Life Limit Block Disabled
ANALOG INPUT
Analog Level 1 Function Disabled
Table 11–6: S4 ELEMENTS (Sheet 11 of 12)
DESCRIPTION DEFAULT GROUP 1 GROUP 2 GROUP 3 GROUP 4
