Basic Operation
Menu System
4. Press the OK button to enter the System menu. The IR Channel setting will be
displayed.
5. Press the ▲ or ▼ buttons to select the Time-Out In Min. menu.
6. Press the OK button to enter the Time-Out In Min. menu. The current timeout value
will be displayed. The default value is ve minutes.
7. Press the ▲ or ▼ buttons to set the timeout value between one and ten minutes.
8. Press the OK button to save the changes.
time-out in min.
enter 1-10 in min:
5
enter 1-10 in min:
2
timeout saved
ir channel
1
OR
LAN
POE
5V DC
1 2
Matrix Controller
Status
IR
Power
Menu
1 2 3
4 5 6
7 8 9
In 0 Out Set
Clear
Mask
Preset
Back
OK
Lock
Basic Operation
