page | 218
Appendix
Updating the Matrix Controller
1.
Download the latest version of rmware from the Gefen Web site.
2.
Extract the .bin le from the .ZIP le.
3.
Access the built-in Web interface and click the
System
tab.
4.
Click the
Browse...
button and select the rmware le.
5.
Click the
Update
button.
(continued on next page)
Firmware Update Procedure
Information
The rmware upgrade procedure can take up to 15 minutes to complete.
Appendix
