Removing Inputs and Outputs
Removing inputs and/or outputs is the opposite of adding them. Removing an input or
output moves it to the Available Inputs or Available Outputs list, respectively, making it
unavailable for routing.
1. Click the Groups tab.
2. Click the Inputs/Outputs tab.
3. Click on the desired group.
4. Start with either the Associated Inputs or Associated Outputs list. The process for
removing inputs or outputs is the same. In this example, we will remove two inputs.
5. Select the desired input(s).
6. Click the arrow icon, pointing to the left.
Basic Operation
Groups
