System > Slave Config
Basic Operation
Web Interface
3 4
1 2
1 Delete Device
Click this button to delete the selected slave Matrix Controller from the list.
2 Show Me
Click this button to show the physical location of the device. When the
Show Me button is clicked, the button text will change to Hide Me and the
following buttons, highlighted in blue, will flash on the front panel of the
Matrix Controller:
Click the Hide Me button to stop the buttons from flashing.
LAN
POE
5V DC
1 2
Matrix Controller
Status
Menu
1 2 3
4 5 6
7 8 9
In 0 Out Set
Clear
Mask
Preset
Back
OK
Lock
page | 165
