Specications
Appendix
Connectors, Controls, and Indicators
LAN 1 • 1 x RJ-45, POE-enabled
LAN 2 • 1 x RJ-45
Power Connector • 1 x locking
Front-panel buttons • 28 x push button, tact-type
IR Sensor • 1 x sensor, front panel
Display • 1 x LCM display
2 lines, 20 characters per line
Power Indicator • 1 x LED, blue
Operational
Power Input • 5V DC
Power Consumption • 4.3W (max.)
Operating Temperature • +32 to +122 ºF (0 to +50 ºC)
Operating Humidity • 5% to 90% RH, non-condensing
Storage Temperature • -4 to +185 ºF (-20 to +85 ºC)
Storage Humidity • 0% to 95% RH, non-condensing
MTBF • 50000 Hours
Physical
Dimensions (W x H x D)
without rack ears
• 17” x 3.5” x 2.7” (432mm x 88mm x 68mm)
Dimensions (W x H x D)
with rack ears
• 19” x 3.5” x 2.7” (482mm x 88mm x 68mm)
Unit Weight • 3.7 lbs (1.7 kg)
