page | 143
Clicking a group button displays additional options within the Main tab.
Basic Operation
Web Interface
1 Block On
Click this button to block the source signal at the input. See Blocking Inputs
(page 54) for more information.
2 Block Off
Click this button to unblock the selected input. See Blocking Inputs (page
54) for more information.
3 Search (Inputs)
Enter the channel, name, or the description of the unit to search for, under
the Inputs column.
4 Ch (Inputs)
Displays the channel of the KVM over IP product.
5 Name (Inputs)
The name of the device.
6 Description (Inputs)
Displays the description of the product. By default, the product name is
used as a description. This name can be changed using the Edit Device
button.
1
2
4 5
6
3
To Next Page
