ID Name Description
1 Preset Press this button to select a preset.
2 Mask Press this button to mask an output.
See Masking an Output (page 91) for
more information.
3 Clear Press this button to clear the current entry.
4 Menu Press this button to access the menu
system.
5 Arrow Buttons Press these buttons to move the cursor
within each setting or to select the desired
menu system.
6 Back Press this button to return to the previous
screen.
7 Numeric Keypad (0 - 9) Use these buttons to enter the desired
values for each setting.
8 In Press this button to specify an input.
9 Out Press this button to specify an output.
10 Set Press this button to accept the current
value.
11 OK Press this button to accept the current
settings.
12 Lock Press this button to lock the front panel.
13 Quick Presets Press these buttons to instantly recall
the desired preset. See Creating Quick
Presets (page 70) for more information.
14 IR Sensor (front of remote) Point the IR sensor at the front panel of the
Matrix Controller.
