10.Coil: remove the helmet compartment to reach
it;
7 - Voltage regulator: remove the right side panel
to reach it.
8 - Immobilizer: remove the shield back plate.
9 / 18 - Saddle opening receiver/ Turn indicator
control device: remove the left fairing to reach
them;
Fuoco 500 i.e. Electrical system
ELE SYS - 7
