MAPLA- Modular energy supply system for load lifting magnets
Operation
Operating in Normal or Material handling mode[A]
6.7 Operating in Normal or Material handling mode[A]
For Normal mode, the switch on the right-hand side of the MMI must be in
the top position[A] = Material handling mode = Normal mode.
In Normal mode, the lifting magnet is switched on by pressing the control
button briey and remains switched on until the control button is pressed
again briey.
6.7.1 Lift load (switch on the lifting magnet)
When switching on the lifting magnet for the rst time after the system
start, quick magnetisation with impulse excitation is not used yet. This rst
magnetisation process lasts approx. 2seconds than the next magnetisation
processes. When using anew iMAPLA system, the characteristic values
of the lifting magnet are measured the rst time the machine is switched
on for safety reasons. In the measurement procedure, it can arise that the
magnetic voltage is reduced slightly. This is raised to the rated voltage
in the permanent mode if the magnetic load is less than or equal to the
max.permissible load on the system.
Ö Lift load (switch on lifting magnet), page23
> Place the lifting magnet on the load to be raised.
> Press the control button briey.
LED 2lights up on the MMI.
y The lifting magnet is magnetised and remains switched on until the
control button is pressed again.
y The load is attracted.
