iMAPLA system description
Components
4 iMAPLA system description
4.1 Components
y Generator
y Switch box with control electronics
y MMI control device (Man-Machine Interface)
4.2 System overview
The iMAPLA system is amodular system for power generation for lifting
magnets and is engineered for used in excavators.
Construction type “One Unit”
The switch box is attached directly to the generator.
Construction type “External Unit”
The switch box and generator are arranged separately.
Note
Follow the installation instructions.
Ö Installation of the switch box,
constructiontype“ExternalUnit”, page92
MMI control device
The MMI control device intelligently controls all system functions and
indicates the operating states. The MMI sends the control information to the
generator.
The MMI is installed inside the cab within the driver's eld of vision to allow
him/her to monitor the indicated operating states.
The MMI control unit is most commonly used as astand-alone version.
Various other options and customer-specic adjustments are possible, e.g.an
MMI with aradio modem.
