iMAPLA system description
GTS type designation and identication
4.10.2 Serial number switch box/controller
The serial number of the electrical controller/switch box is stamped into the
cooling element on the plug side (connection side). This is used for the exact
identication of the electronic components and its programmed software.
Serial number, iMAPLA switch box
Ø 1234 INT 13 - 2 ISO
ISO = tted with optional insulation monitor
2 = number of poles, generator (2=2-pole, 4=4-pole)
(if this entry is not present, the following
generally applies: 8-20kW=2-pole,
21-30kW4-pole)
13 = programmed power class of iMAPLA in kW
INT = iMAPLA indicator (INT)
1234 = Serial number of electronic controller
(4digits for iMAPLA)
Ø = hardware ID, switch box
(Ø = newer version, not used for iMAPLA series 2013)
Serial number, iMAPLA 2013series switch box (with CAN Bus)
12345 I13 G2 -2 ISO Uxx
Uxx = programmed CAN report of the
controller (switch box)
ISO = tted with optional insulation monitor
2 = Number of poles, generator 2=2-pole, 4=4-pole
(ifthis entry is not present, the following generally
applies: 8-20kW=2-pole, 21-30kW 4-pole)
G2 = Identication of the iMAPLA series 2013
I13 = Ig iMAPLA Identication
13 g programmed power class of iMAPLA series 2013in kW
(can also be less than the generator output)
12345 = Serial number of electronic controller
(5characters for iMAPLA series 2013)
