Issue 08/2013 Page 94
MAPLA- Modular energy supply system for load lifting magnets
Installation and commissioning
Commissioning
5.9 Commissioning
CAUTION
In addition to the work given here, checks on the drive system may be
necessary as set out in the requirements and regulations of the drive/system
manufacturer. This also contains the proper attachment of protective covers.
This work must be performed by the person responsible for the machine.
Before commissioning of the iMAPLA system for the rst time, carry out
the following checks. Remove any defects before commissioning. Before
commissioning, read and follow the safety instructions in the General
chapter.
Ö General safety instructions, page58.
> Make sure the performance data of the connected lifting magnet match
the data of your iMAPLA system.
> Make sure the generator is mounted correctly and rmly.
Ö Generator installation for iMAPLA 8, 13, 17and 20, page69
Ö Generator installation for iMAPLA 25and 30, page79
Ö Make sure that the protection covers of the generator drive and the
drive itself are mounted correctly.
> Make sure that the MMI is mounted correctly and in the driver's eld of
view.
Ö General, page29
> Make sure that all connecting cables are correct and are installed correctly
and protected against the mechanical requirements.
Ö Installation of cables, page64.
> Make sure that all connector plugs are plugged in correctly.
> Make sure that the connecting cables between MMI and the control
button are properly connected to the control button unit (joystick).
> Make sure that the total machine meets the requirements of all the
applicable directives.
> Start the system.
Ö Establish the system’s readiness for use, page106.
> Check the correct function of the system by comparing it with the
description.
> Acknowledge the rst start-up in the commissioning report.
Ö Commissioning, page157
