iMAPLA system description
Generator and controller
4.7. 2 Plug connections on the generator and switch box
The connector assignment for 132 (BG132) model generators each with
a2-pole assignment from 8to 20kW rated power:
Generator Socket
connection on
the generator
Cable (s) or
connection to
the switch box
Switch box
Housing weight PE PE
PE
Housing weight
Generator U
C1 C1
1
Generator U
C2 C2
2
C3 C3
3
Generator V
C4 C4
4
Generator V
C5 C5
5
C6 C6
6
Generator W
B1 B1
7
Generator W
B2 B2
8
B3 B3
9
Generator F1+ B4 B4
10
Gen. controller
F1+
Generator F2- B5 B5
11
Gen controller
F2-
NC B6 B6 NC
Fig. 11 iMAPLA 8to 17and 20; plug connection generator switch box
