GTS iMAPLA series - Construction Type External Unit

Issue 08/2013 Page 52
MAPLA- Modular energy supply system for load lifting magnets
iMAPLA system description
Technical data
4.9.2 Construction type “External Unit”
iMAPLA
8
iMAPLA
13
iMAPLA
17
iMAPLA
25
Generator principle Brushless electronic controlled synchronised
generator (three-phase winding)
Nominal output 8kW 13kW 17kW 25kW
Nominal voltage 230V
Surge voltage 280V
Rated current 34.7A 56.5A 73.9A 108A
Permissible speed
range
2800to 4500min
-1
2100to
3600min
-1
Permissible cyclic
duration factor
100 % (continuous operation)
Protection class IP54 (Generator)/IP65 (switch box)
EMC directives
followed
DIN EN 13309/ISO 7637-2/DIN EN 55011;
VDE 0875-11:2011-04and other EMC norms
referenced in the named norms.
Ö References to standards and directives,
page17
Operating conditions Free cooling air feed, unrestricted cooling air
discharge, max.temperature of the sucked cooling
air 40°C; at installation heights <1,000mean sea
level (otherwise, areduction in output of 1 % per
100m over 1,000mean sea level)
External switch box installed vertically with free
convention cooling.
Possible drive types Belt drive, direct drive, direct ange, hydraulic motor
Caution! Observe the manufacturer's instructions
and regulations.
Model 132 160
Dimensions in mm:
Generator with shaft
(length xwidth
xheight)
Switch box
(width xheight
xdepth)
437x 327
x 261
213x 371
x 175
508x 327
x 261
315x 371
x 239
588x 327
x 261
580x 476
x 239
776x 334
x 388
800x 700
x 259
Weight (mass)
- Generator
- Switch box
48kg
14kg
61kg
16kg
80kg
35kg
155kg
85kg
