MAPLA- Modular energy supply system for load lifting magnets
Installation and commissioning
Generator installation for iMAPLA 8, 13, 17and 20
Assembly
Ö Fig. 29, Assembly of the ange mount for the hydraulic drive
(usingiMAPLA 13as an example), page78
> Place the ange[2] onto the generator and secure with four screws[4a].
> Place atoothed washer[4b] underneath the screws and secure with
Loctite.
> Place the collar[1] and clamp securely with two screws.
> Mount the rst half of the coupling[5] on the shaft at the generator and
prevent it from twisting on the shaft using with akey.
> Mount the washer[6] onto the hydraulic motor[8].
> Place the second half of the coupling[5] to the hydraulic motor.
> Place the hydraulic motor[8] with washer[6] and the second half of the
coupling on the generator. Where necessary, turn the coupling slightly to
ensure the gearing locks.
> Place toothed washers[7b] to eight screws[7a] and secure disk[6] to the
ange[2].
> Place the collar[9] onto the coupling unit and tighten rmly with two
screws.
4a M12x 35DIN 912
4b
Spring lock washer DIN 128A-12
7a
M8x 30DIN 912
7b
Spring lock washer DIN 128A-8
Fig. 29 Assembly of the ange mount for the hydraulic drive
(usingiMAPLA 13as an example)
