Page 65 Issue 08/2013
Installation and commissioning
Installation of cables
5.4.1 Pre-assembled cables, supplied
Use the pre-assembled cables ex works which are supplied. These cables
were specially selected for the requirements in such systems and carefully
inspected and, therefore, oer the best-possible guarantee of afault- and
fault-free operation.
If the supplied cables are not used, you must read the chapters
“Requirements for supply cables” and “Information for Han modular
connectors”.
Ö Requirements on the connection cables, page66
Ö Information for Han modular connector cables switch box
liftingmagnet, page67
The connection cable between MMI and control button is delivered
with an open cable end for the connection to the control button and
afully-assembled connector plug for the connection to the MMI.
The connection cable between the switch box and the MMI (for MMIs
with radio modem: between the switch box and radio modem) as well as
the connection cable for the lifting magnet are completely supplied fully
preassembled with plugs.
