GTS iMAPLA series - Table of Contents

Page 3 Issue 08/2013
Legend, safety instructionsContents
Contents
Legend, safety instructions 2
1 Important information and notes 6
1.1 Qualied personnel 6
1.2 Intended use 6
1.3 Validity of the manual 7
1.4 Copyright 8
1.5 General information 8
1.6 Manufacturer's address 8
2 Safety instructions 10
3 References to standards and directives 17
4 iMAPLA system description 19
4.1 Components 19
4.2 System overview 19
4.3 Special properties 22
4.4 Function description 23
4.4.1 Lift load (switch on lifting magnet) 23
4.4.2 Release load (switch o lifting magnet) 24
4.4.3 Overload protection iMAPLA 26
4.5 Generator drive types 28
4.5.1 Drive via belt pulley 28
4.5.2 Direct drive 28
4.5.3 Drive via direct ange 28
4.5.4 Drive via hydraulic motor 28
4.6 MMI control unit (stand-alone version) 29
4.6.1 General 29
4.6.2 MMI displays 30
4.6.3 MMI plug connections (default assignment) 31
4.6.4 Installation 32
4.7 Generator and controller 33
4.7.1 Description 35
4.7.2 Plug connections on the generator and switch box 37
4.8 Dimensions of the systems 42
4.9 Technical data 51
4.9.1 Construction type “One Unit” 51
4.9.2 Construction type “External Unit” 52
4.10 GTS type designation and identication 53
4.10.1 Rating plate, generator 53
4.10.2 Serial number switch box/controller 55
4.10.3 Serial number, MMI control unit 57
