Page 81 Issue 08/2013
Installation and commissioning
Generator installation for iMAPLA 25and 30
5.6.2 Permissible installation position
The generator must be monitored on
ahorizontal surface standing on the
attachment brackets as shown.
The controller (iMAPLA 30) or terminal box
(iMAPLA 25) attached to the generator must
always be on top.
Appropriate special variants with side switch
boxes (controller) can be requested directly from
the manufacturer.
All other installation positions are prohibited!
Do not install the generator in arotated position!
ok
