Installation and commissioning
Generator installation for iMAPLA 25and 30
5.6 Generator installation for iMAPLA 25and 30
y To install the generators, proceed according to the descriptions in this
chapter.
y Prior to installation, read the safety instructions attentively and follow the
instructions and information therein.
Ö General safety instructions, page58
The generator installation is very much the same for the “One Unit” and
“External Unit” construction types. The graphics for the generator installation
apply to the “One Unit” construction type. Anotice is included in the text
where installation for the “One Unit” and the “External Unit” construction
types vary.
Warning
Risk of accident and injury!
y
Incorrectly attached lifting gear can cause accidents.
► Follow the instructions in the Lifting generators and switch
boxes chapter.
Ö Lifting generators and switch boxes, page144
► When using lifting gear on the generator, only use the
provided attachment points.
► Only use suitable lifting equipment.
Important
y
Installing the switch box for “External Unit” systems
Ö Installation of the switch box,
constructiontype“ExternalUnit”, page92
