MAPLA- Modular energy supply system for load lifting magnets
iMAPLA system description
GTS type designation and identication
Type designation, generator
DGGM (BL4) 13 - 2 - ZE
ZE = Twin-bearing version
EE = Single-bearing version
2 = Number of poles, generator
(2=2-pole, 4=4-pole)
13 = Rated output in kW
(BL4) = brushless exciter machine/exciter unit
(BL4 = model 132, BL = model 160)
DGGM
DWG
WG
= AC generator for lifting magnet applications
(MAPLA&iMAPLA)
= Three-phase generator for mains power replacement applications
(notMAPLA)
= Alternator for mains power replacement applications (not MAPLA)
Generator ID number
xxxx stands for the 4-digit generator ID e.g.7677.
xxxx = old MAPLA system, predecessor to the iMAPLA
generations
xxxx-INT13 = iMAPLA system,
position 13indicates the power class in kW.
xxxx-I13G2 = iMAPLA series 2013 (with CAN Bus),
position 13indicates the power class in kW.
